ESU

18mm x 35mm x 11mm

Use with LokSound 5, LokSound 5 Micro & LokSound 5 L Decoders

22mm x 42mm x 8mm

Use with LokSound 5, LokSound 5 Micro & LokSound 5 L Decoders

24mm x 55mm x 8.6mm

Use with LokSound 5, LokSound 5 Micro & LokSound 5 L Decoders

Rectangle (11mm x 15 mm actual speaker size)

Supplied with a sealed mounting plate. First select one of the three base frames subject to the type of speaker you want to assemble, namely a circular frame with either 20mm or 23mm diameter or a rectangular type with 16 x 25mm. After you have inserted the speaker into the base frame you may now determine the height of the speaker baffle. The minimum height is 6mm, which can be raised to 8mm, 9mm, 10mm, 11mm or 13mm by adding up to three intermediate frames. The set contains two 2mm high and one 3mm high intermediate frame. They can easily be fixed with some glue suitable for plastic materials.

Rectangle (11mm x 15 mm actual speaker size)

Supplied with a sealed mounting plate. First select one of the three base frames subject to the type of speaker you want to assemble, namely a circular frame with either 20mm or 23mm diameter or a rectangular type with 16 x 25mm. After you have inserted the speaker into the base frame you may now determine the height of the speaker baffle. The minimum height is 6mm, which can be raised to 8mm, 9mm, 10mm, 11mm or 13mm by adding up to three intermediate frames. The set contains two 2mm high and one 3mm high intermediate frame. They can easily be fixed with some glue suitable for plastic materials.

if you work on locomotives and decoders (e.g. run wires from locomotive to tender), you need thin, extremely flexible cables.

Come in 10 m bundles in all common DCC colors. Colors include: white (Item #51940), purple (Item #51941), black (Item #51942), red (Item #51943), orange (Item #51944), green (Item #51945), grey (Item #51946), yellow (Item #51947), brown (Item #51948), and blue (Item #51949).

Can be wired to all fifth generation ESU decoders (LokSound 5, LokPilot 5, LokPilot 5 Basic). With its energy storage (1.8 Farad capacity) the unit supplies power to all light and motor functions as well as to the sound system. Subject to the energy consumption of your model it may continue to move for up to 1.5 seconds. This extremely flat module is intended for smaller vehicles with moderate power consumption.

The PowerPack Mini XS is equipped with a microcontroller and incorporates an charging circuit controlled by the decoder. Therefore it may be connected even during programming. In order to avoid an undue load on the booster in case there are several models in the same booster sector, the charging current is limited. The buffer time can be reduced by means of a CV. This may be useful to assure the correct stopping position ahead of signals showing the “Stop” aspect (red signal). The output voltage is adjusted fully automatically to the track voltage by the microcontroller in order to avoid flickering of the lighting when buffering is activated.

Can be wired to all fifth generation ESU decoders (LokSound 5, LokPilot 5, LokPilot 5 Basic). With its energy storage (6 Farad capacity) the unit supplies power to all light and motor functions as well as to the sound system. Subject to the energy consumption of your model it may continue to move for up to three seconds.

The PowerPack Midi is equipped with a microcontroller and incorporates an charging circuit controlled by the decoder. Therefore it may be connected even during programming. In order to avoid an undue load on the booster in case there are several models in the same booster sector, the charging current is limited. The buffer time can be reduced by means of a CV. This may be useful to assure the correct stopping position ahead of signals showing the “Stop” aspect (red signal). The output voltage is adjusted fully automatically to the track voltage by the microcontroller in order to avoid flickering of the lighting when buffering is activated.
